| PRODUCT INFORMATION |
EASY painted 90° angled left grab bar
B&M SKU: ID12001V-SX | Idral code: 12001V-SX
|
Product overview
The upright grab bar of the EASY series, available in a right or left version, is designed to guarantee safety and functionality. Made of steel with a tube diameter of 30 mm and dimensions of 350×650 mm, it features a cataphoresis treatment and epoxy powder coating (RAL 9010) for increased corrosion resistance.
Technical details
Item | Detail |
Brand | Idral |
Range | EASY |
Official code | 12001V-SX |
B&M SKU | ID12001V-SX |
Product type | painted 90° angled left grab bar |
Installation | Wall mounted |
Material | Painted steel |
Image | Manufacturer family photo; selected size/orientation is defined by the article code and drawing. |
Rated static load | 150 kg; mounting must follow the applicable technical specification. |
Fixings | Anchors must suit the supporting structure; confirm supply details in the technical specification. |
Technical reference | See ID12001V-SX - Technical Specification for dimensions, materials and supply details. |
